Inflatable Marine Ship Rubber Fender

Marine fender also called pneumatic fender, rubber fender, yokohama fender, made by rubber & multi layer of rubber-dipped tyre fabric, is a leading anti-collision device for marine application in the world today. Marine fenders have become an ideal ship protection medium against collision among ship-to-ship (STS), ship to quay (STQ) and ship-to-berthing (STB), they are widely used for large tankers, vessels, docks, harbor wharfs and ocean platforms.

  • Material: natural rubber, rubber-dipped Nylon cord fabric
  • Lifespan: at least 10 years
  • Guaranty period: at least 24 months
  • Certificate: CCS/EC

Introduction

1. Pneumatic rubber fender make use of inside condensed air as buffer medium, absorb ship attack energy, good resilience, large energy absorb, low reaction force, little surface pressure.
2. Slant compression performance doesn’t lowing down.
3. Good floating performance doesn’t effect by tide scope, fender can be kept at an ideal waterline.
4. Installation and taking convenient, it widely used all kinds of vessel, barge, large scale dock and dock with large tide scope.

Material of Ship Rubber Fender

1. Fender body material: natual rubber, rubber dipped Nylon cord fabric.
2. Outer tire and chain net: tire, chain, rubber sleeve, flange, towing ring, shackle, swivel
3. Tire: aircraft tire, car tire.
4. Chain: hot galvanized or stainless steel.
5. Flange: hot galvanized or stainless steel.
6. Towing ring: hot galvanized or stainless steel.
7.Shackle: hot galvanized or stainless steel.
8.Swivel: hot galvanized or stainless steel.
9. Initial Internal Pressure :0.05MPa, 0.08MPa.

Structure of Yokohama Fender

ship rubber fender

Application & Storage of Rubber Fender

1. The fender pressure should be kept in the standard pressure ,within the rate of ± 5% range.
2. Often check the pressure , when the pressure drops, Inflate the fender in time,  so as not to affect the normal use of the fender.
3. When connecting the fender with a steel wire rope, the wire rope should be fitted with a rubber sleeve to avoid damage to the fender
4. Do not touch the fender surface with the the sharp objects , to prevent piercing the fender. If the fender’s surface is damaged, it will affect the lifespan of the fender.
5. When the fender is in normal use, the fixing points should be firm, prevent the detachment and wash away the fender. Suspension of the rope and hook ring should be connected orderly , can’t be in a mess.
6. If the fender won’t be used in a long time , to clean the fender surface with fresh water, and place the fender in a dry, cool, ventilated place, without direct sunshine.
7. When the fender is stored for a long time, the pressure should be reduced and the fender should be placed far away from the heat source.
8. Because the fender is rubber product, should try to avoid the fireworks, not contact with acid, alkali, oil and other organic solution
9. When the fender is stored, it shall not be folded or stacked, and don’t stack other objects on the fender.
